Jiangxi Huatesheng New Material Limited Company PVB interlayer film factory
7 Years
| Ask Lasest Price | |
| Brand Name : | ZHECHUN |
| Model Number : | CZ01 |
| Payment Terms : | T/T, L/C |
| Supply Ability : | 15,000,000 square meter per year |
| Delivery Time : | 10 days after deposit |
PVB middle film is translucent membrane, PVB film is mainly used for sandwich glass, is between the two pieces of glass clip into a layer of PVB film, after high-pressure composite, heating and special glass.PVB laminated glass with safety, heat preservation, noise control and isolation of multiple functions such as uv, widely used in construction, automotive industry, photovoltaic, etc.
| Product name | PVB interlayer |
| Raw material | The resin |
| Thickness | 0.38mm 0.76mm 1.14mm 1.52mm (±0.02mm) |
| Appearance | Achromatic or light yellow clear film, smooth surface without scratch or crease |
| Dotted Impurities and Air Bubbles | >0.05mm²(Allowed to scatter no more than 10 places per roll) >0.55mm²(Not to exceed 6-8 places per roll; Marking marks, add an extended 1 meter film per place |
| Uniformity | Lateral and longitudinal evenness degree shouldn’t exceed 15μm at a distance of 25mm Lateral deviation should be less than 35μm, while longitudinal deviation should be less than 25μm |
| Length Tolerance(m) | +(0-2) |
| Width Tolerance(mm) | +(10-20) |
| Water Content (%) | ≥0.05 |
| Tensile Strength(Mpa) | ≥20 |
| Haze (%) | <0.7(0.38*2) |
| Shrinkage(60℃/15min)(%) | ≤12 |
| Elongation at break(%) | ≥200 |
Advantage for PVB laminated glass:
Safety
Energy saving
Sound proof
Laoding:about 20,000 square meter/20 feet container
|
|
